Chilling Circulator Low Temperature Benchtop Water Bath 6L 10L 15L 20L

Short Description:

Model: DCW series–Bench top laboratory refrigerated thermostatic heating cooling circulating water bath.

Key Specifications:
Temperature resolution: 0.01℃. Temperature Fluctuation: ± 0.05 °C. Material: 304 stainless steel.

DCW-0506 Specifications:
Temperature range: -5 to +100℃, 6L. Pump flow: 6 L/min.

2. Premium Material: The stainless steel work surface of the lab cooler is widened and thickened, and the whole machine adopts electrostatic spraying technology to prevent rust. Stainless steel cover and hidden handle design make it more convenient.

3. High Quality Circulating Pump: The cooling chiller circulation system consists of internal and external circulation. The circulating pump adds a cooling fan, which is more durable and prolongs the service life.

4. INTELLIGENT CONTROL: Intelligent instrument control, easy to operate, can correct the deviation of the temperature measurement value, high-temperature control accuracy, and good stability.

5. PROTECTION SYSTEM: The refrigeration has overheating and over current protection. The control system has over-temperature tweet alarms, which can set the upper and lower limits of the temperature. The over-temperature alarm temperature can automatically cut off the load when over-temperature.

6. Heat Emission Hole: The Low-temperature chillers are designed with multiple vent holes for rapid heat dissipation and stable temperature.

7. Draining Valve: The refrigerated water chiller adopts an Invisible drain valve design, clean appearance, more convenient drain.

8. WIDE APPLICATION: Recirculating water cooling Chiller is particularly suitable for chemical, biological, and physical laboratory work under normal conditions or where low temperatures are required.

Send email to us

Product Detail

Product Tags

Introduction

Laboratory Refrigerated Thermostatic Water Bath are widely used in biology, chemical engineering, chemistry, pharmaceuticals, life sciences, and physical property testing. Provide users with a controlled cold and hot field source with uniform and constant temperature. Conduct constant temperature experiments or tests on experimental samples or produced products, and can also serve as a heat or cold source for direct heating or cooling and auxiliary heating or cooling.

Product Features

The latest self-developed temperature control technology, equipped with high standard PT100 and fully imported electronic components.
● The software system can correct the error between the displayed temperature and the actual temperature, so that the displayed temperature value is accurate.
● Standard large screen LCD display, many data at a glance, temperature display resolution up to 0.01℃.
● With over-temperature protection, over-temperature alarm, over-temperature alarm temperature can be set, and the load can be cut off automatically when the temperature is over.
● Timing function, the total working time of the equipment can be set and the load can be cut off automatically when the time comes.
● Hidden cooling coil design ensures larger space for use in the tank.
● Intelligent software with strong temperature stability, PID can automatically adjust the best parameters according to different media, and special users can also manually readjust the parameters.
● Digital locking of the control system with the software can avoid wrong operation by unrelated personnel and ensure the correct data of the experiment process.
● High efficiency totally enclosed compressor refrigeration, fast cooling speed, with multiple protection such as overheating and over-current.
● Standard equipped with international needs of users in multiple scenes.
